Gunsmithing M16 extractor for Remington 223

[HadesPrecision]

Does anyone know where I can get an M16 style extractor for a Remington 700 .223 and a print for installation? PTG told me their mini one won’t work for it and LRI isn’t showing their mini one available to order. I can do the install myself and would rather not have to send my bolt off.

Also for clarification, I don’t want a sako style extractor. And no, it’s not a matter of needing a new factory extractor or ejector. I’ve gone 3 of each without the problem being solved (one of the ejectors I lengthened to come almost flush with the bolt nose). The only cases that don’t just fall in the receiver are Lapua and even then it’s only 90% of the time they eject at all. It seems that they’re the only ones with a thick enough rim. All others extract just fine but pop loose before they eject and I have to physically remove the spent case by hand.



[VSP968]

I realize your asking about extractors and prints but I just had one installed by LRI on a R700 224 Valkyrie bolt gun build (.420 bolt face) but he does them for all other calibers.

Call them. They may be of assistance.



[Alan Warner]

I made some some time ago and have a dozen or so. PHT 4140. Install is self explanatory. Spring is up to you.



[Easy_E]

If your a do it yourselfer the Badger M16 extractor comes with instructions . https://www.badgerordnance.com/media/bo_media/306-90_91_92_Extractor.pdf



[LRI]

LRI Mini M16's arrived from heat treat yesterday. Were updating the store now.



[DannG]

Just adding to the knowledge base as best I can.
My Rem 700 Tactical ( .223) always had weak extraction, often dumping the case in the breech. I changed the extractor with another from Remington, same issue.
I recently installed a new extractor from PTG and the problem has cleared up.
HTH,
DannG



[HadesPrecision]

Just adding to the knowledge base as best I can.
My Rem 700 Tactical ( .223) always had weak extraction, often dumping the case in the breech. I changed the extractor with another from Remington, same issue.
I recently installed a new extractor from PTG and the problem has cleared up.
HTH,
DannG

Just for clarification, you installed the factory style extractor from PTG or replaced it with either a sako or m16 style?



[DannG]

The factory style replacement. They were bare steel ( I bought 3 of 'em....). I parkerized them before install, so far, so good.
DannG
