I ordered an accuracy international ax50 in January, paid in full and is supposed to be here soon. I just ordered a Schmidt and Bender 5-25x56 pm2 p4l fine moa FW scope, long range accuracy f class bipod, and the AI 45 MOA scope mount. I have a Leupold 65inlb torque t handle. Is this the torque I should use?
I used it only sako trg with warne mount with zeiss 6-20x50 . The sako shoots great to 600 yards ( I've never shot it farther). This gun/scope is so much more expensive I want to mount it perfect. Any other tips would be appreciated.
Thanks



[avidflyer]

I torque my AI mounts to 18 for the rings and 31 for the base. Do a search the AI values have been posted several times.



[samnev]

I also use 18" pounds on rings but use 40" pounds on the base. I have the 20 moa AI mount.



[bcrich]

65" pounds of torque for rings sounds too much! That's what I torque my stock to.



[Rthur]

NightForce manuals say 25 in/# for ring screws and 68 in/# for crossbolt on rings. I have been using 15 in/# on ring screws and 65 in/# for the crossbolts. Haven't had a scope move yet.


R



[Quarter Horse]

Check with the manufacturer of each component for the manufacturer's suggested torque levels. Also note that torque settings are almost always quoted for a completely dry screw and nut or hole. If your components are not clean and dry you will be significantly over-torquing. With that kind of investment, you should definitely buy one of the Borka, torque wrench, tool kits. A search will give you lots of reviews for the Borka.

I pm'd Boris, the tool's designer and manufacturer, with a question regarding torque settings for lubed parts and the use of loc-tite. His response for parts lubed with oil or grease was to reduce the torque value by 35%. As regards loc-tite he cautioned against it's use. With that caution in mind, he said that a wild-ass-guess for loc-tite would be a 25% reduction and that I would be proceeding at my own risk. As you probably know, this is in reference to blue loc-tite.

For the invaluable advice received in this thread, you are expected to post pics and a range report ASAP. LOL



[Pleistarchus]

2nd the motion for pics and range report



[0724/1030]

1. upper ring cap screws: 2.0nm / 18 in/lb.
2. scope mount clamp screws: 3.5nm / 31 in/lb.



[GeKados]

You find some values for AI rifles in the photo below. For AX I don't have anything so is better to check with the manufacturer like everybody said.



For my AE , I use IOR scope and rings, the torque value (recommended by IOR) are:

- rings caps (steel rings) 20 lbs-in or 2,2 N/m
- rings to picatinny base : 65 lbs-in or 7,3 N/m



[nathan4x4]

I ordered the borka after i got the first reply with the lower torque numbers. I am still waiting on the AX 50 but my scope is here... you would think after i paid $12,000 for gun and magazines and bipod on Jan 1st that I'd have it by now. The store said 4 people had over 4,000 worth of accessories so they got theirs first.

I have my Sako TRG with my ziess 6.5-20X50 on the warne base with warne mounts. I am thinking its overtorqued now.... It shoots great, any reason to readjust with new torque wrench? 550Yd groundhog shot is farthest I have tested it. 250 range its sub .5MOA with nosler custom competition brass and 168 nosler CC or ballistic tip.



[nathan4x4]

Here at last

Wife went and picked up gun and my son gave me his vortex red dot off of his S&W15-22.. We all shot a couple rounds. Gun is huge, wife is 5-10

S&BPM2 should be here tomorrow



[sniperdude]

same for me to

NightForce manuals say 25 in/# for ring screws and 68 in/# for crossbolt on rings. I have been using 15 in/# on ring screws and 65 in/# for the crossbolts. Haven't had a scope move yet.


R



[nathan4x4]

TRG and AI at range

<a href="http://s1290.photobucket.com/user/nathan4x4/media/IMG_20130720_114600_981_zpsfe4475a9.jpg.html" target="_blank"><img src="http://i1290.photobucket.com/albums/b524/nathan4x4/IMG_20130720_114600_981_zpsfe4475a9.jpg" border="0" alt=" photo IMG_20130720_114600_981_zpsfe4475a9.jpg"/></a>

<a href="http://s1290.photobucket.com/user/nathan4x4/media/IMG_20130707_200748_114_zps2303f876.jpg.html" target="_blank"><img src="http://i1290.photobucket.com/albums/b524/nathan4x4/IMG_20130707_200748_114_zps2303f876.jpg" border="0" alt=" photo IMG_20130707_200748_114_zps2303f876.jpg"/></a>

<a href="http://s1290.photobucket.com/user/nathan4x4/media/IMG_20130723_214634_325_zpsca5b6fa8.jpg.html" target="_blank"><img src="http://i1290.photobucket.com/albums/b524/nathan4x4/IMG_20130723_214634_325_zpsca5b6fa8.jpg" border="0" alt=" photo IMG_20130723_214634_325_zpsca5b6fa8.jpg"/></a>

This is TRG with 4 shot group @ 200 Nosler CC 168 and Nosler brass RL15

I dont have AX50 sighted in yet because I realized the 45MOA base and the PMII 5-25 with MOA doesnt have enough adjustment to shoot anywhere close at 200 yards. We normally shoot at 200 at the club by our house and anything 500-1000 is a drive so I ordered a 28MOA Eurooptic base and will be shooting it soon.
I also realized I can't shoot 50 for shit yet because I am definitely not used to the recoi even if it is 17MOA high.



[scudzuki]

Wife went and picked up gun and my son gave me his vortex red dot off of his S&W15-22.. We all shot a couple rounds. Gun is huge, wife is 5-10

S&BPM2 should be here tomorrow

That's a great pic. Your wife looks super enthused.
