Berger 175 OTM for .308 Win ELR Shooting

MidRangeCrisis

Private
Minuteman
Aug 22, 2020
66
36
I've been out of the game for a while but I'm glad to be back. Big plans here...

One of them is to get into ELR with my .308 and I am meant to understand that the Berger 175 OTM was designed by Bryan Litz with a lot of impetus on trans-sonic stability in mind. I know I have a lot of reading to do but I wanted to start this thread and hopefully garner some lessons learned from those out there making attempts like what I have in mind.

My platform is my Tikka T3 "Multi-Match Rifle" which is a T3 action in an Elisio tube chassis with the following specs:

30" Bartlein .299/.308 1:12" Medium Palma barrel
Chambered with a PTG Bisley 150 Palma reamer
Norma .308 brass with an average volume of 58.2 grains of H2O
Tula Large Rifle Primers
47.7 grains of IMR-4166 yields 2840 fps (according to Quickload...so far has been very good guesses in .308)

I have ordered a small sample of Berger 175s to load up and test but I wanted to know if there are other bullets I should be looking at for this.


ubettcha

Private
Belligerents
Minuteman
Dec 23, 2017
877
4,551
With a 12 the FTR 155's can be better if you can run them hard enough. I'm running the 150 Lehigh @ 3015fps with a trued .515 G1 out to 980yds. I hope to shoot this out far enough to find transonic in a month when I can get back to the range.

  • Like
Reactions: MidRangeCrisis

MidRangeCrisis

Private
Minuteman
Aug 22, 2020
66
36
With a 12 the FTR 155's can be better if you can run them hard enough. I'm running the 150 Lehigh @ 3015fps with a trued .515 G1 out to 980yds. I hope to shoot this out far enough to find transonic in a month when I can get back to the range.
I'll have to look at Lehigh bullets again. Missed tgat one. Any thoughts on the Warner or Peregrine equivalents?


ubettcha

Private
Belligerents
Minuteman
Dec 23, 2017
877
4,551
I'll have to look at Lehigh bullets again. Missed tgat one. Any thoughts on the Warner or Peregrine equivalents?
Awesome stuff just about double what the lehigh is in price. The Lehigh in my rifle a 13ish to 12gain tw Rock Creek I have pushed them harder with CFE223 but I have a ton of Rl15 with the same accuracy just not as fast. I have also run the 195tmk in my gun with cfe for great results but it is close to wobbly at 40 degrees. I don't have any more cfe to figure out my drops beyond 650 however the bc has been within .2 mils to there so far. I have pushed this to 2760 and shoot it at 2707 with single digit es. .5 inches at 300yds but it is a full mil left of my regular 168smk load and I think .1 or 2 higher. This is loaded long @ 2.940 and I believe that is the cause of my difference in zero being so drastic. Pretty much everything in the 150-185 range is a few .1ths up or down or to the side. nothing at sub 300yds where I do most of my shooting

  • Like
Reactions: MidRangeCrisis

MidRangeCrisis

Private
Minuteman
Aug 22, 2020
66
36
Awesome stuff just about double what the lehigh is in price. The Lehigh in my rifle a 13ish to 12gain tw Rock Creek I have pushed them harder with CFE223 but I have a ton of Rl15 with the same accuracy just not as fast. I have also run the 195tmk in my gun with cfe for great results but it is close to wobbly at 40 degrees. I don't have any more cfe to figure out my drops beyond 650 however the bc has been within .2 mils to there so far. I have pushed this to 2760 and shoot it at 2707 with single digit es. .5 inches at 300yds but it is a full mil left of my regular 168smk load and I think .1 or 2 higher. This is loaded long @ 2.940 and I believe that is the cause of my difference in zero being so drastic. Pretty much everything in the 150-185 range is a few .1ths up or down or to the side. nothing at sub 300yds where I do most of my shooting
Can you point me to the lehigh bullet? I can't find it.

Apparently the 175 OTM was designed for ELR applications. Something about bullet shaped

  • Like
Reactions: E-Tool

jbailey

Gunny Sergeant
Belligerents
Minuteman
Jul 27, 2010
1,983
640
47
Arlington VA
With a 12 the FTR 155's can be better if you can run them hard enough. I'm running the 150 Lehigh @ 3015fps with a trued .515 G1 out to 980yds. I hope to shoot this out far enough to find transonic in a month when I can get back to the range.
You don't have the twist to shoot the Warner Flatlines. 11twist or better in 30cal, unless you are on top of the Rockies, in which case the 160s might do the job. They are beasts if you can get them going into good stable groups.

With your setup, you might want to try the 185gr Juggs as well. They are outstanding and will give you a bit more wind performance.

  • Like
Reactions: MidRangeCrisis

ubettcha

Private
Belligerents
Minuteman
Dec 23, 2017
877
4,551
You don't have the twist to shoot the Warner Flatlines. 11twist or better in 30cal, unless you are on top of the Rockies, in which case the 160s might do the job. They are beasts if you can get them going into good stable groups.

With your setup, you might want to try the 185gr Juggs as well. They are outstanding and will give you a bit more wind performance.
I'm all set it is the OP that asked about the flatlines. The TMK's shoot in my rifle if I want to run them. Thx for that info.


MidRangeCrisis

Private
Minuteman
Aug 22, 2020
66
36
You don't have the twist to shoot the Warner Flatlines. 11twist or better in 30cal, unless you are on top of the Rockies, in which case the 160s might do the job. They are beasts if you can get them going into good stable groups.

With your setup, you might want to try the 185gr Juggs as well. They are outstanding and will give you a bit more wind performance.
I've had mixed results with Juggernauts in the past but I have some coming just in case for my 1:10" application.

Any opinion on the 175 OTM? It seems to be the medicine in my 1:12 according to the math


jbailey

Gunny Sergeant
Belligerents
Minuteman
Jul 27, 2010
1,983
640
47
Arlington VA
I'm all set it is the OP that asked about the flatlines. The TMK's shoot in my rifle if I want to run them. Thx for that info.
oops , sorry, yeah, I was answering the OP's question.

@MidRangeCrisis
Negative, I have no experience w/ the 175gr OTMs, so I can't offer any opinion. I too read that they transition well thru sound barrier, so you are probably on the right track. Good luck in any case. Shooting ELR with a 308 is fun and rewarding, truly a great learning experience. I have had Warner Flatlines 198grs from a 308 out a long ways, regularly and fairly easily impacting at over of 1 mile.

  • Like
Reactions: MidRangeCrisis

MidRangeCrisis

Private
Minuteman
Aug 22, 2020
66
36
47.7 grains of IMR4166 under 175’s is way way too much.
Running them at 2.950" in the Quickload model. Of course I'll dial it i once I have the bullets in hand to measure off of and knock it back at least 10% to start.

What does your experience show with IMR 4166? I've been able to get fairly good results off of an interpolated model. That said, it's a first time using Quickloads model with 4166 data.


918v

Volumetric Meterer
Belligerents
Minuteman
Jul 15, 2007
3,621
1,180
Miserable CA
Why would you run them that long? There’s hardly any bullet in the case that way. In my TRG22 they hit the lands at 2.930”.

Did you look at Hodgdon’s data? That’s in a Winchester case with more capacity than Norma. At 47.7grs you’ll eat the bolt.

  • Like
Reactions: MidRangeCrisis

GIXXER2000

ELR Junkie
Belligerents
Minuteman
  • Aug 5, 2013
    1,221
    425
    Bullhead City ,AZ
    I took the old 308 out for some ELR shooting today. We shot from 375 my warm up shot all the way out to 1626 which is a far as my scope will dial. It was a great day with the wind at 2mph at max. I am shooting an AI-AE with a 26 in 1-10 twist barrel. The round is as follows;
    Bullet 178ELD-X
    Primer CCIBR2
    Brass Blackhills match
    Powder Varget 42.3
    AVG FPS 2641
    SD 7.9
    COAL is 2.86


    MidRangeCrisis

    Private
    Minuteman
    Aug 22, 2020
    66
    36
    I took the old 308 out for some ELR shooting today. We shot from 375 my warm up shot all the way out to 1626 which is a far as my scope will dial. It was a great day with the wind at 2mph at max. I am shooting an AI-AE with a 26 in 1-10 twist barrel. The round is as follows;
    Bullet 178ELD-X
    Primer CCIBR2
    Brass Blackhills match
    Powder Varget 42.3
    AVG FPS 2641
    SD 7.9
    COAL is 2.86
    Awesome! Sounds like the wind gods were favoring you.

    I ran your load in QL 3.9; calculates at 56,962 psi and 2638 fps. I guess they have the program pretty well dialed in for Varget at least.

    Based on the AB application's calculations, it looks like you were trans-sonic starting at about 1200 yards and subsonic after 1300 or so. How did the ELD-X fare for you at the far end of the range?


    MidRangeCrisis

    Private
    Minuteman
    Aug 22, 2020
    66
    36
    Why would you run them that long? There’s hardly any bullet in the case that way. In my TRG22 they hit the lands at 2.930”.

    Did you look at Hodgdon’s data? That’s in a Winchester case with more capacity than Norma. At 47.7grs you’ll eat the bolt.
    I'll review the published data but unless they ran it well out past 2.80", it's hard to make a reasonable comparison.

    I've modeled several variations of OAL from 2.780-2.950" and not really gained much at the top end more than about 40 FPS. That said, it remains to be seen what the bullets will measure out at in my chamber. It's cut for 155 SMK or equivalent Palma bullets loaded long to give as much case capacity as possible. As for cases, I'd have to measure a batch or two again but if memory serves the Normas proved to be very high quality with nearly the same capacity as the Winchester cases. I might be thinking of the 30-06 cases but I recall that the .308 was pretty respectable.


    GIXXER2000

    ELR Junkie
    Belligerents
    Minuteman
  • Aug 5, 2013
    1,221
    425
    Bullhead City ,AZ
    We'll never used Quick Load but from what you said my load looks to be spot on. Yes the wind gods were smiling on us. Today was the 1st day we shot at this location and things went well. This spot is more suited for the .300 on up then close in. There are good sight lines out past 4k. The 178-ELD-X was better then i thought it would be pasted 1200. It stayed right on target al the way out to 1626.

    Last edited:

    918v

    Volumetric Meterer
    Belligerents
    Minuteman
    Jul 15, 2007
    3,621
    1,180
    Miserable CA
    I'll review the published data but unless they ran it well out past 2.80", it's hard to make a reasonable comparison.

    I've modeled several variations of OAL from 2.780-2.950" and not really gained much at the top end more than about 40 FPS. That said, it remains to be seen what the bullets will measure out at in my chamber. It's cut for 155 SMK or equivalent Palma bullets loaded long to give as much case capacity as possible. As for cases, I'd have to measure a batch or two again but if memory serves the Normas proved to be very high quality with nearly the same capacity as the Winchester cases. I might be thinking of the 30-06 cases but I recall that the .308 was pretty respectable.
    Norma 308 brass is like current Hornady and Remington capacity-wise. When you’re loading that long and that close to the lands you risk blowing primers.

    My experience with 4166 is not great. I bought an 8 pound jug when it first came out and loaded it using Hodgdon’s data in Winchester brass. I did not find it as good as 4064. The accuracy window was small. I think it’s better for lighter bullets, kinda like Ramshot TAC is. Pressure comes on fast. I wouldn’t use it for what you want to do. I would go with CFE223.

    I get 2770 FPS with the OTM out of my 26” TRG slow ass barrel and .190” groups. It’s stupid accurate and not all that temperature sensitive, 40-50 FPS over 100 degrees.

    • Like
    Reactions: MidRangeCrisis

    MidRangeCrisis

    Private
    Minuteman
    Aug 22, 2020
    66
    36
    Norma 308 brass is like current Hornady and Remington capacity-wise. When you’re loading that long and that close to the lands you risk blowing primers.

    My experience with 4166 is not great. I bought an 8 pound jug when it first came out and loaded it using Hodgdon’s data in Winchester brass. I did not find it as good as 4064. The accuracy window was small. I think it’s better for lighter bullets, kinda like Ramshot TAC is. Pressure comes on fast. I wouldn’t use it for what you want to do. I would go with CFE223.

    I get 2770 FPS with the OTM out of my 26” TRG slow ass barrel and .190” groups. It’s stupid accurate and not all that temperature sensitive, 40-50 FPS over 100 degrees.
    I bought 48 pounds back when I was more able to take Palma shooting seriously and I still have a bunch. Works well enough with 155s ayway. I may just get some CFE223 OR RL-16 for this though.


    MidRangeCrisis

    Private
    Minuteman
    Aug 22, 2020
    66
    36
    Norma 308 brass is like current Hornady and Remington capacity-wise. When you’re loading that long and that close to the lands you risk blowing primers.

    My experience with 4166 is not great. I bought an 8 pound jug when it first came out and loaded it using Hodgdon’s data in Winchester brass. I did not find it as good as 4064. The accuracy window was small. I think it’s better for lighter bullets, kinda like Ramshot TAC is. Pressure comes on fast. I wouldn’t use it for what you want to do. I would go with CFE223.

    I get 2770 FPS with the OTM out of my 26” TRG slow ass barrel and .190” groups. It’s stupid accurate and not all that temperature sensitive, 40-50 FPS over 100 degrees.
    I ran the numbers in QL for the CFE223...that is some snazzy stuff! I was able to get my hands on a pound to test with and a box of 100 Berger 175 OTM as well.

    With a load density at 102% I'm showing very high ballistic efficiency and total powder burn in the 30" barrel with ~2935 fps; does that seem right to you?


    FCS

    Gunny Sergeant
    Commercial Supporter
    Belligerents
    Minuteman
    Jun 3, 2005
    2,058
    405
    ABQ, NM
    www.mccourtmunitionsllc.com
    Berger 175 Long Range Target / LRBT is 10 gr lighter version of the 185 Juggernaut.
    185 would be my suggestion but if not, then the 175 LRT. 175 OTM is very tractable, we’ll behaved bullet but not my first choice for 1000 yd or farther shooting.

    • Like
    Reactions: MidRangeCrisis

    MidRangeCrisis

    Private
    Minuteman
    Aug 22, 2020
    66
    36
    Berger 175 Long Range Target / LRBT is 10 gr lighter version of the 185 Juggernaut.
    185 would be my suggestion but if not, then the 175 LRT. 175 OTM is very tractable, we’ll behaved bullet but not my first choice for 1000 yd or farther shooting.
    Thanks man that's awesome insight. I've had mixed results with the 185 Juggernaut but I am going to give it another try. I tend to shoot at very low altitude and I think I may not be getting all the benefits of the 185 down here. In any case, I'll give the 175 LRBT a go as well as the OTM.


    Xcount

    Sergeant
    Belligerents
    Minuteman
    Jul 31, 2009
    239
    22
    Have you contacted Berger? They have a very responsive tech support. I think that most of the trans-sonic effects are from the boattail design. I'm just another guy on the internet though, call Berger.

    • Like
    Reactions: MidRangeCrisis

    MidRangeCrisis

    Private
    Minuteman
    Aug 22, 2020
    66
    36
    Have you contacted Berger? They have a very responsive tech support. I think that most of the trans-sonic effects are from the boattail design. I'm just another guy on the internet though, call Berger.
    I have. The basic answer was "Bryan Litz designed the 175 OTM for transonic stability. It should be well behaved." I read up on the characteristics that were deemed desirable fir that behavior though and the 175 LRBT might have an edge in ghat department with it's shorter boat tail.
