I dont want to derail this thread too much....

From a mathematical standpoint UNITY means 1. So when talking about clip on thermal sights it means that the little display your dvo is looking at is exactly 1.0x to agree with the outside environment. Not 1.2 or 1.05 or 1.003x. Turning a diopter on a device that is UNITY can alter that. For example lets say you're holding a skeetir up to your right eye with both eyes open and your looking at a person 20 feet away. With diopter set correctly to UNITY that person blends perfectly between both eyes. The top of the guys head lines up perfectly both visually and through the thermal. The real world and the thermal are in perfect UNITY together. So if I were to turn that diopter a bit I could misalign the top of the guys head between my two eyes. Now you don't have a UNITY display and you would introduce error in your poi especially when using high magnification in your dvo and/ or Dialing your turrets.
So basically if your skeetir diopter is set perfectly to UNITY then it should work the way it was intended. Adjustable diopters are needed when working with differing human eyeballs so they're typically employed on multi use devices like the skeetir that will have a hand held or helmet mount role....so the guy with 20/40 near sight vision can still have a clear image.

Parallax introduced from your dvo is another related topic we can cover later.


WhereNow&How

Major Hide Member
Full Member
Minuteman
Nov 10, 2019
1,769
1,978
MS
I’m more of a “working definitions” guy than a dictionary definitions guy, so someone may try to correct me from a dictionary standpoint, but in common usage on the Hide over the last few years…

UNITY is getting the image SIZE correct. If you already have a true 1X thermal it is already at “unity”. If a thermal has a 3X front end architecture, it needs 3X demagnification so that the end result is your day scope seeing things at “1X”.

COLLIMATION is getting the screen LOCATION correct, either through a prism or through adjusting the margins on the screen “sighting in the screen”.

Lining up the various day/night scopes in the same optical plane is a good idea. It helps with collimation but it (in itself) isn’t collimation.

Similarly, adjusting a thermal’s diopter removes parallax and will help, but it (in itself) does not collimate the device. It’s is possible to have a perfectly adjusted diopter and be nowhere near collimated.
Good stuff and makes sense to me.


WhereNow&How

Major Hide Member
Full Member
Minuteman
Nov 10, 2019
1,769
1,978
MS
I dont want to derail this thread too much....

From a mathematical standpoint UNITY means 1. So when talking about clip on thermal sights it means that the little display your dvo is looking at is exactly 1.0x to agree with the outside environment. Not 1.2 or 1.05 or 1.003x. Turning a diopter on a device that is UNITY can alter that. For example lets say you're holding a skeetir up to your right eye with both eyes open and your looking at a person 20 feet away. With diopter set correctly to UNITY that person blends perfectly between both eyes. The top of the guys head lines up perfectly both visually and through the thermal. The real world and the thermal are in perfect UNITY together. So if I were to turn that diopter a bit I could misalign the top of the guys head between my two eyes. Now you don't have a UNITY display and you would introduce error in your poi especially when using high magnification in your dvo and/ or Dialing your turrets.
So basically if your skeetir diopter is set perfectly to UNITY then it should work the way it was intended. Adjustable diopters are needed when working with differing human eyeballs so they're typically employed on multi use devices like the skeetir that will have a hand held or helmet mount role....so the guy with 20/40 near sight vision can still have a clear image.

Parallax introduced from your dvo is another related topic we can cover later.
Good stuff and makes sense. Thanks. I now have a better understanding of what UNITY really means.


WhereNow&How

Major Hide Member
Full Member
Minuteman
Nov 10, 2019
1,769
1,978
MS
So does the SkeetIR or Voodoo S have the ability to adjust the margins or are they just perfectly aligned with the sensor and display such that they are a true plug and play.


Evolution 9

Hurter of feelings
Supporter
Full Member
Minuteman
Supporter+
Mar 6, 2010
983
988
Central Idaho
On a thermal....collimation is sensor and display being in perfect alignment. .....edit...........and eyepiece not altering that relationship to your day optic.

No, it’s more than that.

If sensor and display are in perfect alignment, but pointed in a slightly different direction than the day scope (it will ALWAYS be pointed slightly different) you will have point of impact deviations.

Something may have been lost in translation from the engineer you talked with. There is more engineering at play, either a prism or some other wizardry.

If it was about making the display true to its own sensor, then you could collimate a commercial clip on just one time, and then move it from gun to gun to gun. But we all know you can’t.

Military thermal clip ons work even when out of line (20 MOA rails, etc.)

Getting the display perfectly lined up with the sensor only helps if the sensor is pointed perfectly in line with the scope (which will never happen).

Turn your phone camera on.
Hold your finger above your screen over an item in the center of the field of view (to simulate your crosshairs).
Now angle your phone to the left.

Your finger is no longer over the item.
This has nothing to do with the alignment of your phone’s screen to its lense…

It happened because your phone was angled to the left…

The same thing happens when you mount a clip on without a prism (or some other wizardry.


DownRangeThermal

scout alias hoginaustin
Supporter
Commercial Supporter
Full Member
Minuteman
Supporter+
Feb 16, 2017
502
915
Austin TX
www.downrangethermal.com
So does the SkeetIR or Voodoo S have the ability to adjust the margins or are they just perfectly aligned with the sensor and display such that they are a true plug and play.
They should be digitally aligned and plug and play as long as no error is introduced as described above.

  • Like
Reactions: WhereNow&How

GreenMushroom

Gunny Sergeant
Full Member
Minuteman
Nov 27, 2020
659
504
Washington
I dont want to derail this thread too much....

From a mathematical standpoint UNITY means 1. So when talking about clip on thermal sights it means that the little display your dvo is looking at is exactly 1.0x to agree with the outside environment. Not 1.2 or 1.05 or 1.003x. Turning a diopter on a device that is UNITY can alter that. For example lets say you're holding a skeetir up to your right eye with both eyes open and your looking at a person 20 feet away. With diopter set correctly to UNITY that person blends perfectly between both eyes. The top of the guys head lines up perfectly both visually and through the thermal. The real world and the thermal are in perfect UNITY together. So if I were to turn that diopter a bit I could misalign the top of the guys head between my two eyes. Now you don't have a UNITY display and you would introduce error in your poi especially when using high magnification in your dvo and/ or Dialing your turrets.
So basically if your skeetir diopter is set perfectly to UNITY then it should work the way it was intended. Adjustable diopters are needed when working with differing human eyeballs so they're typically employed on multi use devices like the skeetir that will have a hand held or helmet mount role....so the guy with 20/40 near sight vision can still have a clear image.

Parallax introduced from your dvo is another related topic we can cover later.

If the clip on has a reticle, it can help to turn it on. If not, dial up day scope magnification until you can see individual pixels.

Now, adjust the clip on diopter while moving your head up down left and right. You’ll notice the day scope crosshairs moving in relation to the clip on crosshairs (or pixels). Pretty soon, all movement between the two crosshairs will stop. That’s when you have it right.

As you’ve no doubt noticed, it’s much like removing day scope parallax just with a different thing being adjusted.

It’s worth noting that most people recommend having the day scope parallax set to infinity if the scope is so equipped.

I'll have to get back out and try this. I remember the scope crosshairs moving in relation thermal crosshairs but I was only adjusting the diopter for image quality and not paying attention to other effects it might have. I'm after a fairly niche usage here so haven't put the time into it. I mostly want this for daytime use on a carbine in front of a small lpvo. If the easiest way is to have it be a fixed 2.5-3x that's fine with me. We have a ton of cold heavily overcast days here and the nox is pretty useful in those conditions but I hate having my eye jammed in a cup during the day.


Squibbler

Supporter
Supporter
Full Member
Minuteman
Supporter+
Apr 6, 2014
562
501
In the name of multi- functionality, why not make a locking diopter with a 1x unity detent. At least for the multi role sized units, it could provide the best to both use cases.
