Warner Tool .300WM Build *COMPLETE w/ PICS

Tactical30

Tactical30

Gunny Sergeant
Full Member
Minuteman
May 5, 2009
1,098
3
46
Eastern Ohio
#1
I recieved this build back a couple months ago but just got finally around to posting pics:

Thanks to the Warner's (Warner Tool Co.) they make a beautiful rifle.

The weather has been so bad here and I have been so busy I have not had time to shoot it yet but I do have so 208gr. A-MAX's, 220gr. SMK's and 190gr. SMK's loaded up with H-1000 and RL-22 to test. I just got some of the new Hornady 225gr. BTHP's yesterday. Im going to try them with H-1000 or Retumbo first.

<span style="text-decoration: underline">Here is the Specs and Pics:</span>

Bartlien 26" #7 MTU Contour 1-10 Twist bbl
Badger FTE Brake
McMillan A-5 Stock w/ Adj. Cheekpiece
Rem700 L/A Blueprinted, Marine Tex Bedded.
Surgeon KMW Bolt Knob
Warner Tool Recoil Lug
20 MOA Base opened up to 8-40 Screws
Badger M5 Bottom Metal
CG Jackson Trigger Mod-22
Accushot Atlas Bipod V8
Accushot 3.5" Bipod Rail
Nightforce 3.5-15x50 NXS w/ NP-R1 Reticle
Badger USMC DMR Rings (1.031")
All metal Coated in Birdsong Tan-T

Its a 16lb BEAST!!








#2
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

I hear Mr Warner builds a fine rifle. Nice looking rig.

How do you find that Jackson match trigger? I used to run one but found the shoe would keep working itself loose after a while.

#8
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

Any 300WM is a good rifle
, but that one is beautiful... very nice.

Looking forward to the range report... especially on those 225's. Thanks for sharing..

John

#11
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

<div class="ubbcode-block"><div class="ubbcode-header">Originally Posted By: NRAShooter</div><div class="ubbcode-body">Very nice. How does it shoot? </div></div>

If you read my whole post. I said I have not had time and crappy (snow) weather. I cant wait to get this rifle broken in!

I will shoot some Federal FGMM 190gr. and some Black Hills 190gr. to get it sighted in and then I will go to the 208gr. A-MAX, 225gr. Hornady BTHP, 220gr. SMK Reloads. Cant Wait!!

I will post the range reports with the chrono results also.

#13
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

I measured some of the new 225gr. Hornady bullets compared to the 220gr. SMK (measured 10 bullets and took an average):

<span style="text-decoration: underline">220gr. Sierra Matchking</span>
Ogive Length: .900"
OAL: 1.490"

<span style="text-decoration: underline">225gr. Hornady BTHP</span>
Ogive Length: .900"
OAL: 1.580"

It looks like the 220gr. SMK Load data will work pretty good for a starting point for the 225gr. Hornady BTHP if you reload.

#14
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

<div class="ubbcode-block"><div class="ubbcode-header">Originally Posted By: Priest</div><div class="ubbcode-body">I hear Mr Warner builds a fine rifle. Nice looking rig.

How do you find that Jackson match trigger? I used to run one but found the shoe would keep working itself loose after a while. </div></div>

The guys @ Warner Tool had ordered the trigger for me but I seen them in stock at Bauer arms the last time I checked.

#16
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

<div class="ubbcode-block"><div class="ubbcode-header">Originally Posted By: longrange30</div><div class="ubbcode-body">I measured some of the new 225gr. Hornady bullets compared to the 220gr. SMK (measured 10 bullets and took an average):

<span style="text-decoration: underline">220gr. Sierra Matchking</span>
Ogive Length: .900"
OAL: 1.490"

<span style="text-decoration: underline">225gr. Hornady BTHP</span>
Ogive Length: .900"
OAL: 1.580"

It looks like the 220gr. SMK Load data will work pretty good for a starting point for the 225gr. Hornady BTHP if you reload. </div></div>



So how did those 225grainers shoot?????

#17
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

I will post all data of the 225gr. Hornady BTHP bullets I shot I while back in the next 3 days (im out of town and dont have the data on me)
Stay Tuned!

I have the data with H-1000 and Retumbo along with some other data. The 208gr. A-MAX's are in in love with this rifle!

The guys at Warner Tool sure know how to make an accurate rifle. The farthest range i was able to get to so far was 600yrds. It held MOA no problem out that far. I cant wait to stretch it out to 1000yrds+ and see what it can really do.

It took me 11.5 MOA to get out to 600yrds with Factory Black Hills and FGMM 190gr. SMK's.

The wieght of the rifle (17lbs loaded) and the Badger FTE brake surprised the hell out of me of how much it tamed the recoil but the guys shooting next to me where kinda pissed!...LOUD!

<span style="text-decoration: underline">Rounds Fired:</span>
Factory Black Hills 190gr. SMK
Factory FGMM 190gr. SMK
208gr. A-MAX w/ H-1000
225gr. BTHP w/ H-1000
225gr. BTHP w/ Retumbo

<span style="text-decoration: underline">Still To test:</span>
190gr. SMK w/ RL-22
210gr. Berger w/ H-1000
210gr. Berger w/ RL-22
208gr. A-MAX w/ Retumbo
208gr. A-MAX w/ RL-22


#18
Re: Warner Tool .300WM Build *COMPLETE w/ PICS

Really interested to see what you come up with on the 225gr BTHP. I have a few of these that I want to try and am interested to see what results others are getting with them. I hope ends up liking Retumbo so I can run the same powder as in my other magnums.
