Thanks, I'm no way as experienced as you men so I learn a lot here. It is usually right on but I don't have a place to shoot past 600. The wind is a bigger challenge for me than drop.
- Thread starter Ppierceall
- Start date
Thanks, I'm no way as experienced as you men so I learn a lot here. It is usually right on but I don't have a place to shoot past 600. The wind is a bigger challenge for me than drop.
D
Deleted member 10043
Guest
It is good to know regardless that you are limited to 600 yards for the time being. With that in mind consult with Doc on whether the average single BC is the more practical choice. I believe it is.
This is a great thread...read it multiple times and participated early on. There are still some outstanding questions that I can't wrap my arms around...they have been asked previously by others as well.
- Everyone says tweak your measured MV. Based on what I have read, the initial MV can be a complete guess. Why use a chronograph to measure MV, if it has to be changed to make the solver agree with reality? I am not a ballistician but I create electromagnetic models for communication systems. I have a good feeling that the underlying model has limitations or the numerical methods for solving the equations of flight are flawed. Either way, why buy a chronograph other than for safe load development?
- If you use a CDM versus a G1 or G7 BC, do you still tweak MV at 500 yards? Since there is no BC, do you rely on DSF versus truing the BC? My issue with DSF is that it requires a huge amount of distance to use. It is really impractical. For this reason, I am thinking of going back to G1 or G7. If @DocUSMCRetired can chime in, that would be great.
1. No, you dont need a chrono...it can just make things faster...with the tools and gear we have these days (magneto/LabR), you can pretty much go from zero to hitting 600-800 yd targets with minimal effort...in all my barrels and rifles, i rarely have to tweak my MV more than 20-25 fps...inside 600 yds, its typically just getting my formula to round +/- 0.1mil. It only really comes into play when we are shooting 1moa or less targets (especially diamonds)...if you have to start tweaking MV (and generally BC) a ton, chances are there is something else off somewhere in the solver or rifle system...scope tracking errors can be meshed in there as well, accurately measuring a scopes tracking is harder for most than they think...its easy to induce a small % error or not catch one
2. cant help here...dont use the CDMs myself...easier to do what i need via g1/g7
I use CD and after truing MV @500y, I verified out to 1k and didn't need to adjust DSF, and the AB team says you usually shouldn't need to but have the ability to if needed.
I may need to as I stretch beyond 1k and move through transonic.
I may need to as I stretch beyond 1k and move through transonic.
When you true MV you are often negating out other nuances in the rifle system.
When it comes down to it, the laws of physics and the drag modeling are pretty simple. Its the variations in different rifle systems that causes complexities and the need for truing.
When it comes down to it, the laws of physics and the drag modeling are pretty simple. Its the variations in different rifle systems that causes complexities and the need for truing.
I can believe that. If the bullet left the barrel exactly the way the model assumes it does, maybe truing would not be necessary but I can see a variety of issues corrupting the ideal representation of a bullet in flight.
Lindy wrote this a bunch of years ago, might help some
Shooters using ballistic programs often find that their field shooting data does not precisely agree with the output from their program.
In addition, shooters comparing the outputs of different programs often find significant discrepancies between the programs. Why?
Below are listed the cause of some inaccuracies in the elevation predictions of ballistic programs. Windage calculations are beyond the scope of this article.
Uncalibrated scope clicks. For example, Leupold M1 dials I have tested are closer to 1 inch per hundred yards than 1 MOA. With a typical .308 load at 1000 yards, the difference in point of impact is about 20 inches. If you don't know how to check that calibration, you may find this article useful: Optically Checking Rifle Scopes
Normal variations in muzzle velocity. A good load may have a muzzle velocity standard deviation of 15 feet per second. That means that about two-thirds of the shots will fall in the range from 15 fps per second above the average velocity to 15 feet per second below the average. At 1000 yards with a typical .308 load, that range of variations will cause shots distributed over a 10 inch range. Nota bene: About one third of the shots will have variations from the average which are even greater. There are many causes of this velocity variation, and they are beyond the scope of this article.
Temperature variations in muzzle velocity. A pretty good powder will exhibit a variation in muzzle velocity of 1 foot per second per Fahrenheit degree. If you chronographed your load at 85 degrees and are shooting at 55 degrees, your muzzle velocity may be 30 feet per second slower than you think it is. I have measured variations as large as 5 feet per second per Fahrenheit degree. The only way to know how big that variation is, is to test it. In addition, my experience has been that the standard deviation of the muzzle velocity increases at low temperatures.
Muzzle velocity measurement errors. Do you believe your chronograph is accurate? The screen spacing of most chronographs is too short for accurate measurement. Some chronographs like the Oehler 35 series allow extending the spacing. The clock frequency of many chronographs is too slow to get accurate and consistent measurements, i.e., more than one shot with the identical muzzle velocity will be displayed with different measurements. Other common problems with chronograph data is failing to compensate for the distance between the muzzle and the chronograph screens, and failing to fire enough rounds to have a good average velocity. People with little understanding of statistics may have a very vague idea of what the chronograph output means. See Statistics for Rifle Shooters
Ballistic coefficient variations. Most manufacturers publish only G1 BCs for their bullets. The G1 coefficient doesn't match very well the shape of modern boattail bullets. To accomodate that, Sierra publishes BCs for their bullets in velocity ranges. However, many ballistic programs are not set up to handle multiple BC values. A better match to boattail bullets is the G7 BC, which will produce a better calculation of bullet velocity at range, which is useful to shooters who are operating near the transonic range of their bullets. Some bullets exhibit unpredicable behaviour in the transonic range. The Sierra 168 grain Matchking is one such bullet.
One source of G7 BCs produced by extensive testing is the book Applied Ballistics for Long Range Shooting, 3rd Edition by Bryan Litz. I highly recommend this book for anyone serious about shooting at extended distances.
In addition, the online program JBM Ballistics has some G7 BCs in its bullet library. It does not tell you what the G7 BC is - just select the a bullet with the label "(Litz)" after the listing in the bullet library. If there is no such label after the bullet you are using, a G7 coefficient is not available. Also select G7 in the main screen.
Range uncertainty. This is a prime cause of differences between the ballistic program output and field shooting data at long range. At 1000 yards with our typical .308 load, a range error of 20 yards will cause an elevation error of about 18 inches, which is 0.5 mil or almost 2 MOA. You may believe your laser rangefinder is accurate - but a one percent error at 1000 yards is 10 yards, and that's assuming that you actually managed to laser the target. The manufacturer of the common Leica 1200 claims an accuracy of +/- 0.5 percent beyond 800 yards.
Elevation variations caused by the headwinds or tailwinds. Headwinds slightly increase the drag on the bullet, and tailwinds reduce it. Not all ballistics programs correctly model this effect.
Aerodynamic jump. This is Bryan Litz's description of this factor: "Aerodynamic jump is what causes groups to slant when shot in varying wind conditions. Basically, when the bullet exits the muzzle into a cross wind, the bullet tries to yaw slightly to align itself with the airflow. When the bullet yaws to the side, gyroscopic action causes it to nose up or down by a small amount depending on the wind direction. This initial yaw has an effect on the trajectory, and is known as aerodynamic jump. The more severe the cross wind, the more pitch the bullet ends up with. Flying to the target at a pitch angle will result in an elevation error that's proportional to crosswind." From: Extending the Maximum Effective Range of Small Arms. That's a good article which describes some of the limitations of existing ballistic programs.
The Eötvös effect. This is an elevation variation caused by the earth's rotation. It is of most significance on long shots taken directly due east or west. Some ballistics program do not correctly model this effect. Bryan's Litz's book previously referenced has a section on how to calculate that effect if your ballistic program does not. The magnitude of this variation might be in the range of 10 inches maximum difference on a 1000 yard shot between a due east shot and a due west shot, depending on your lattitude.
Incorrect specification of atmospheric parameters. Many shooters do not understand the difference between station pressure and barometric pressure referenced to sea level. See Barometric Pressure and Ballistic Software.
Error in Inclined Shot Calculations. Many ballistic program do not correctly compensate for the difference between an uphill shot, where gravity slightly hinders the bullet, and a downhill shot, where gravity is slightly aiding the bullet. For example, on a 900 yard shot at a 30 degree angle, the difference between an uphill shot and a downhill shot is about one MOA. The magnitude of this difference increases with the angle. Most programs I have seen are doing a calculation appropriate to an uphill shot, so what one might do to compensate for that is to hold a little low on a downhill shot.
An additional possible error on an inclined shot is failure to compensate for the difference in air density between the firing position and the target. For example, on a 900 yard shot at a 30 degree angle, the altitude difference between the firing position and the target is 1350 feet. No ballistic program I am aware of attempts to compensate for that difference.
Parallax error caused by improper adjustment. When looking through the scope at the target, the reticle should not appear to move relative of the target when you make a slight movement of your head. If it does, parallax error is present and should be corrected.
Zero errors. If your hundred yard zero is off by a quarter of an inch, at 1000 yards your point of aim will be off by 2.5 inches.
Shooter variations. We have seen two shooters have different points of impact on the same target at long distance using the same rifle and load. That's because of differences in the way the rifle is held by the shooter.
Differences in atmospheric modeling between the programs.
Light and Mirage. When there is sunshine, there will be some mirage, even when the temperature is very low—I have seen mirage when there was snow on the ground. Mirage and bright light may make the target look higher in the scope than it is, especially if the target is white or a bright color. If there is significant crosswind, the target may appear to be offset in the downwind direction as well.
Now What?
Now that we know some of the causes, and have eliminated or compensated for as many of the variables as we can, what can we do?
We can systematically modify the program output by shooting long-range with our load, and then adjusting the muzzle velocity or BC input to the program until the program output matches the shooting data. I typically do this at a range of 1000 yards with a .308. Nota bene: it should be done at a range and under conditions where you know the bullet has not entered the transonic region. We might say the bullet has entered the transonic region if its velocity has decreased to within 110 percent of the speed of sound. (The speed of sound is about 1125 feet per second at 68 degrees F. It varies only with temperature.) So, if the speed of sound is 1125 feet per second, we might say the bullet is in the transonic region when the speed has dropped to 1238 fps.
If other sources of error discussed above have not been ruled out, it should be obvious that the correction obtained by this process will apply only to this load fired from one specific rifle with one specific scope - maybe.
Understand from this discussion that no ballistic program can produce an output sufficiently accurate to guarantee a first-round hit at ranges beyond a few hundred yards. A ballistic program is correctly used to get you close to that first-round hit under conditions you don't normally shoot in. An example is training with your rifle and load at sea level, and then trying to make a high-altitude shot.
When someone says that their un-tuned ballistic program was "right on at 1000 yards", I generally conclude that if they are telling the truth, they were lucky enough to have offsetting errors.
* Revision History:
July 3rd, 2010. All that was changed was a link to the Engleman article on chronograph statistics.
October 27, 2018. Added effects of light, updated some links.
Shooters using ballistic programs often find that their field shooting data does not precisely agree with the output from their program.
In addition, shooters comparing the outputs of different programs often find significant discrepancies between the programs. Why?
Below are listed the cause of some inaccuracies in the elevation predictions of ballistic programs. Windage calculations are beyond the scope of this article.
One source of G7 BCs produced by extensive testing is the book Applied Ballistics for Long Range Shooting, 3rd Edition by Bryan Litz. I highly recommend this book for anyone serious about shooting at extended distances.
In addition, the online program JBM Ballistics has some G7 BCs in its bullet library. It does not tell you what the G7 BC is - just select the a bullet with the label "(Litz)" after the listing in the bullet library. If there is no such label after the bullet you are using, a G7 coefficient is not available. Also select G7 in the main screen.
An additional possible error on an inclined shot is failure to compensate for the difference in air density between the firing position and the target. For example, on a 900 yard shot at a 30 degree angle, the altitude difference between the firing position and the target is 1350 feet. No ballistic program I am aware of attempts to compensate for that difference.
Now What?
Now that we know some of the causes, and have eliminated or compensated for as many of the variables as we can, what can we do?
If other sources of error discussed above have not been ruled out, it should be obvious that the correction obtained by this process will apply only to this load fired from one specific rifle with one specific scope - maybe.
When someone says that their un-tuned ballistic program was "right on at 1000 yards", I generally conclude that if they are telling the truth, they were lucky enough to have offsetting errors.
* Revision History:
July 3rd, 2010. All that was changed was a link to the Engleman article on chronograph statistics.
October 27, 2018. Added effects of light, updated some links.
Thank you Lowlight for posting that. Very good read, and gave me an understanding of how to deal with things I was unsure of.
Use this, it should help. It also has spots for notation: http://appliedballisticsllc.com/Articles/Firing Solution Check List.pdf
So I trued my mv on my 5700 elite the way kestrel recommends. It works really well for me using factory ammo and using the cdm. Now I’m working up a new load and was wondering if I should stick with what works or true the bc. I only have access to a 600 yard range and occasionally 1000. Is 600 too close to true bc? I know frank says 800, but I don’t have access to that.
The honest answer is yes it somewhat matters. You want to pick a distance that is close enough that the BC cannot influence the drop as much is a velocity. But the key is not to pick it so close that the shooters error influences the result more than the drop.
500 yards is the Goldilocks zone. Considering your .9 Solid to your .4 Flat base, 400-600.
Now before everyone gets all excited because they have an AB custom curve, You need to understand that they’re asking for velocity a little bit further to blend the results. This is a deficiency because they don’t think you’re smart enough to tune the form factor. The drop scale factor, Is better suited for deep transonic but will jack up your close range curve if you need to bend it too much.
Last edited:
The problem with truing in a Kestrel is that once you start using the system to adjust MV or DSF it then ignores your MV/temp calculations. In other words, your newly adjusted MV remains fixed irrespective of future temp changes. You can’t have both. So you have an adjusted MV/BC that is only good in one set of conditions.
All you do is turn the MV table off, use the MV calculator, take the values it gives you, input them into the MV/temp table, then turn the table back on.
Managing Muzzle Velocity & MV Variation - Applied Ballistics LLC
As a refresher here are a couple bullet points before we get started: 1. Chronographs measure velocity at their location, not Muzzle Velocity. Muzzle Velocity needs to be properly calculated Read More ...
appliedballisticsllc.com
Lindy wrote this a bunch of years ago, might help some
Shooters using ballistic programs often find that their field shooting data does not precisely agree with the output from their program.
In addition, shooters comparing the outputs of different programs often find significant discrepancies between the programs. Why?
Below are listed the cause of some inaccuracies in the elevation predictions of ballistic programs. Windage calculations are beyond the scope of this article.
Uncalibrated scope clicks. For example, Leupold M1 dials I have tested are closer to 1 inch per hundred yards than 1 MOA. With a typical .308 load at 1000 yards, the difference in point of impact is about 20 inches. If you don't know how to check that calibration, you may find this article useful: Optically Checking Rifle Scopes
Normal variations in muzzle velocity. A good load may have a muzzle velocity standard deviation of 15 feet per second. That means that about two-thirds of the shots will fall in the range from 15 fps per second above the average velocity to 15 feet per second below the average. At 1000 yards with a typical .308 load, that range of variations will cause shots distributed over a 10 inch range. Nota bene: About one third of the shots will have variations from the average which are even greater. There are many causes of this velocity variation, and they are beyond the scope of this article.
Temperature variations in muzzle velocity. A pretty good powder will exhibit a variation in muzzle velocity of 1 foot per second per Fahrenheit degree. If you chronographed your load at 85 degrees and are shooting at 55 degrees, your muzzle velocity may be 30 feet per second slower than you think it is. I have measured variations as large as 5 feet per second per Fahrenheit degree. The only way to know how big that variation is, is to test it. In addition, my experience has been that the standard deviation of the muzzle velocity increases at low temperatures.
Muzzle velocity measurement errors. Do you believe your chronograph is accurate? The screen spacing of most chronographs is too short for accurate measurement. Some chronographs like the Oehler 35 series allow extending the spacing. The clock frequency of many chronographs is too slow to get accurate and consistent measurements, i.e., more than one shot with the identical muzzle velocity will be displayed with different measurements. Other common problems with chronograph data is failing to compensate for the distance between the muzzle and the chronograph screens, and failing to fire enough rounds to have a good average velocity. People with little understanding of statistics may have a very vague idea of what the chronograph output means. See Statistics for Rifle Shooters
Ballistic coefficient variations. Most manufacturers publish only G1 BCs for their bullets. The G1 coefficient doesn't match very well the shape of modern boattail bullets. To accomodate that, Sierra publishes BCs for their bullets in velocity ranges. However, many ballistic programs are not set up to handle multiple BC values. A better match to boattail bullets is the G7 BC, which will produce a better calculation of bullet velocity at range, which is useful to shooters who are operating near the transonic range of their bullets. Some bullets exhibit unpredicable behaviour in the transonic range. The Sierra 168 grain Matchking is one such bullet.
One source of G7 BCs produced by extensive testing is the book Applied Ballistics for Long Range Shooting, 3rd Edition by Bryan Litz. I highly recommend this book for anyone serious about shooting at extended distances.
In addition, the online program JBM Ballistics has some G7 BCs in its bullet library. It does not tell you what the G7 BC is - just select the a bullet with the label "(Litz)" after the listing in the bullet library. If there is no such label after the bullet you are using, a G7 coefficient is not available. Also select G7 in the main screen.
Range uncertainty. This is a prime cause of differences between the ballistic program output and field shooting data at long range. At 1000 yards with our typical .308 load, a range error of 20 yards will cause an elevation error of about 18 inches, which is 0.5 mil or almost 2 MOA. You may believe your laser rangefinder is accurate - but a one percent error at 1000 yards is 10 yards, and that's assuming that you actually managed to laser the target. The manufacturer of the common Leica 1200 claims an accuracy of +/- 0.5 percent beyond 800 yards.
Elevation variations caused by the headwinds or tailwinds. Headwinds slightly increase the drag on the bullet, and tailwinds reduce it. Not all ballistics programs correctly model this effect.
Aerodynamic jump. This is Bryan Litz's description of this factor: "Aerodynamic jump is what causes groups to slant when shot in varying wind conditions. Basically, when the bullet exits the muzzle into a cross wind, the bullet tries to yaw slightly to align itself with the airflow. When the bullet yaws to the side, gyroscopic action causes it to nose up or down by a small amount depending on the wind direction. This initial yaw has an effect on the trajectory, and is known as aerodynamic jump. The more severe the cross wind, the more pitch the bullet ends up with. Flying to the target at a pitch angle will result in an elevation error that's proportional to crosswind." From: Extending the Maximum Effective Range of Small Arms. That's a good article which describes some of the limitations of existing ballistic programs.
The Eötvös effect. This is an elevation variation caused by the earth's rotation. It is of most significance on long shots taken directly due east or west. Some ballistics program do not correctly model this effect. Bryan's Litz's book previously referenced has a section on how to calculate that effect if your ballistic program does not. The magnitude of this variation might be in the range of 10 inches maximum difference on a 1000 yard shot between a due east shot and a due west shot, depending on your lattitude.
Incorrect specification of atmospheric parameters. Many shooters do not understand the difference between station pressure and barometric pressure referenced to sea level. See Barometric Pressure and Ballistic Software.
Error in Inclined Shot Calculations. Many ballistic program do not correctly compensate for the difference between an uphill shot, where gravity slightly hinders the bullet, and a downhill shot, where gravity is slightly aiding the bullet. For example, on a 900 yard shot at a 30 degree angle, the difference between an uphill shot and a downhill shot is about one MOA. The magnitude of this difference increases with the angle. Most programs I have seen are doing a calculation appropriate to an uphill shot, so what one might do to compensate for that is to hold a little low on a downhill shot.
An additional possible error on an inclined shot is failure to compensate for the difference in air density between the firing position and the target. For example, on a 900 yard shot at a 30 degree angle, the altitude difference between the firing position and the target is 1350 feet. No ballistic program I am aware of attempts to compensate for that difference.
Parallax error caused by improper adjustment. When looking through the scope at the target, the reticle should not appear to move relative of the target when you make a slight movement of your head. If it does, parallax error is present and should be corrected.
Zero errors. If your hundred yard zero is off by a quarter of an inch, at 1000 yards your point of aim will be off by 2.5 inches.
Shooter variations. We have seen two shooters have different points of impact on the same target at long distance using the same rifle and load. That's because of differences in the way the rifle is held by the shooter.
Differences in atmospheric modeling between the programs.
Light and Mirage. When there is sunshine, there will be some mirage, even when the temperature is very low—I have seen mirage when there was snow on the ground. Mirage and bright light may make the target look higher in the scope than it is, especially if the target is white or a bright color. If there is significant crosswind, the target may appear to be offset in the downwind direction as well.
Now What?
Now that we know some of the causes, and have eliminated or compensated for as many of the variables as we can, what can we do?
We can systematically modify the program output by shooting long-range with our load, and then adjusting the muzzle velocity or BC input to the program until the program output matches the shooting data. I typically do this at a range of 1000 yards with a .308. Nota bene: it should be done at a range and under conditions where you know the bullet has not entered the transonic region. We might say the bullet has entered the transonic region if its velocity has decreased to within 110 percent of the speed of sound. (The speed of sound is about 1125 feet per second at 68 degrees F. It varies only with temperature.) So, if the speed of sound is 1125 feet per second, we might say the bullet is in the transonic region when the speed has dropped to 1238 fps.
If other sources of error discussed above have not been ruled out, it should be obvious that the correction obtained by this process will apply only to this load fired from one specific rifle with one specific scope - maybe.
Understand from this discussion that no ballistic program can produce an output sufficiently accurate to guarantee a first-round hit at ranges beyond a few hundred yards. A ballistic program is correctly used to get you close to that first-round hit under conditions you don't normally shoot in. An example is training with your rifle and load at sea level, and then trying to make a high-altitude shot.
When someone says that their un-tuned ballistic program was "right on at 1000 yards", I generally conclude that if they are telling the truth, they were lucky enough to have offsetting errors.
* Revision History:
July 3rd, 2010. All that was changed was a link to the Engleman article on chronograph statistics.
October 27, 2018. Added effects of light, updated some links.
This is an awesome post!
I dont know who Lindy is but hes a smart feller it seems.
