New 6mm Advanced Rifle Cartridge

MaxSpring

Supporter
Supporter
Minuteman
Oct 30, 2018
11
6
Current load I’m using in this build is:

28.5 Gr Leverevolution on 103 Berger Hybrids at 1.664 CBTO. Average Vel - 2527. ES 12, SD 6.2. Sub 1/2 MOA. This is out of an 18 Proof. Thinking about ordering something longer from Craddock.


Attachments

  • 580D14F0-D0E2-4765-B1CE-3C559A62065E.jpeg
    946.6 KB · Views: 109

newageroman

Sergeant of the Hide
Full Member
Minuteman
Jul 13, 2018
163
48
www.brassbucket.net
1k Match Results posted: lots of wind. I qualified very quickly in the morning. I can see the advantage of funning a semi and the holds on the scope/vs dialing also helped speedily hit targets at 600/750/1k. Scored some hits on the first round and after that went downhill. the wind was ~11 headwind most of the day at the bench, but down-range it was gusting and switching constantly.
next month is back to 600yds but there is another 1k in August.

  • Like
Reactions: TripleBull

fifdynutz

Pasture Poodle
Full Member
Minuteman
May 5, 2020
184
41
Iowa
scored a 500ct of sierra tipped game king 90's. going to do some side by side comparisons of them vs. the 90 eldx with the same data soon.

  • Like
Reactions: godofthunder

Ledzep

Chancellor
Full Member
Minuteman
  • Jun 9, 2009
    3,579
    3,328
    NE
    Any ideas on the barrel life of a 6ARC?
    I have 2 barrels that both have about 3000 rounds on them and they're still going strong. Based on powder volume vs. bore area, and just how the barrels look at various round counts vs. 6.5 Creedmoor, I'm guessing 4000-6000. Basically at every time I bore scoped them they looked like a 6.5 creed with half as many rounds.

    ETA: Both of those are bolt-gun barrels I've been running 60ksi loads with, too. AR's with 52ksi loads should go a touch longer... Depends on where you call it for accuracy, too. I could see serviceable accuracy for 7-10k.


    godofthunder

    Sergeant
    Supporter
    Commercial Supporter
    Full Member
    Minuteman
    Oct 2, 2013
    546
    284
    Nebraska
    www.rustynutsdesigns.com
    scored a 500ct of sierra tipped game king 90's. going to do some side by side comparisons of them vs. the 90 eldx with the same data soon.
    Interested in your findings. Scored 500 of those as well a while back but haven't even set my XL750 up yet so got a ways before I'll be doing any loading. Hoping these work well for coyotes.


    fifdynutz

    Pasture Poodle
    Full Member
    Minuteman
    May 5, 2020
    184
    41
    Iowa
    i recieved my arm or ally brass yesterday and it converted perfectly. ive always had great luck with arm or ally with ship times.

    I also worked on some of my load development with my faxon 14.5" 6arc setup i use to night hunt. Ive been shooting the hornady black 105's all season with great luck. I chose the load on these that best matched the factory ammo (that shot great in this barrel) and loaded them to be super reliable, and are surprisingly pretty fur friendly. They have proven flat enough i can aim on fur out to 300 "ish" with a 50yd zero

    Currently building a 16" setup so i can compare speeds with the same loads and help contribute to some barrel length calculations.

    here is the data i landed on so far for 103g ELDX and 90g ELDX. I tried both varget and CFE with CFE providing much higher velocities. i may load a few boxes of varget just for the below zero nights we may be hunting.

    1x hornady case
    14.5" faxon heavy profile
    mid length gas-unsuppressed
    CCI BR4
    1.70 O-Give (matches factory hornady black)
    stone cold reliable piece in all weather conditions so far

    VARGET 90g ELD-X
    27.8-2450
    28.0-2465 - best SD
    28.2-2496

    VARGET 103g ELD-X
    26.0-2260
    26.2-2300

    CFE 90g ELD-X
    30.0-2663
    30.2-2700 - best SD
    30.4-2710

    CFE 103g ELD-X
    26.8-2290
    27.0-2320


    I just scored some LVR from precision reloading and 500ct 90g sierra TGK's a couple weeks ago. i think i am going to keep my CFE for the loads i already developed (90+103eldx)

    Where would be a good starting point for development with the sierra 90's and Lever? I'm fresh out of new hornady 6arc brass for testing so i may used some of the new 6.5g starline i held back for development. Thanks!


    LRBuck

    Private
    Minuteman
    Sep 25, 2020
    40
    33
    I saw in the Powder In Stock thread that Midway has the CCI #41 primers in stock. Complaints about the price but since I am running low I ordered. Limited to only 1000 at a time which sucks with the hazmat fee.

    Question: anybody loading these for their 6 ARC? What can I expect to be different than with #400s - which is mostly what I have had to shoot?

    • Like
    Reactions: fifdynutz

    Gtscotty

    Gunny Sergeant
    Full Member
    Minuteman
    Jul 22, 2018
    584
    454
    Got confirmation yesterday from Legacy Sports that they will be importing Howa mini actions in 6mm ARC Q1 or Q2 of 2021.

    I assume you meant 2022 right? If so that's what they told me in an email a few months ago as well. I can't wait to get one, should be an excellent, handy platform for the little ARC.


    AZgeek

    Private
    Supporter
    Full Member
    Minuteman
    Sep 30, 2014
    654
    256
    Tucson AZ
    I saw in the Powder In Stock thread that Midway has the CCI #41 primers in stock. Complaints about the price but since I am running low I ordered. Limited to only 1000 at a time which sucks with the hazmat fee.

    Question: anybody loading these for their 6 ARC? What can I expect to be different than with #400s - which is mostly what I have had to shoot?
    Looked at that primer offering. With tax, shipping and hazmat it was like $124.00 total. I had to pass.


    newageroman

    Sergeant of the Hide
    Full Member
    Minuteman
    Jul 13, 2018
    163
    48
    www.brassbucket.net
    Here's my target from a couple weeks ago testing higher velocities with the CCI41 primers. My wife had my stapler, and I had limited supply of sticks to mount the targets so I decided to try and get some multiple groups on the same plate. one of my tricks is stapling on the side of the plate (assuming your rifle/bullets shoot straight).

    Well, I was holding a bit high for 100yds(zeroed for 600). The first group had 3 or 4 shots cloverleafing (at least 3 shots touching), I'm not sure about the other 1 or 2 shots in that group. The bottom group is the fastest I'm gonna go and still sub MOA. I'm going to load up a hundred more in the top and bottom group and have see what turns out.
    Still sitting on a sack of 500 new Grendle Cases that need to be formed too...


    Attachments

    • targets.jpg
      36.4 KB · Views: 83

    fifdynutz

    Pasture Poodle
    Full Member
    Minuteman
    May 5, 2020
    184
    41
    Iowa
    What are you guys running for OAL with the 90g tgk's? I'm having a hell of a time getting mine to chamber properly


    ormandj

    Supporter
    Supporter
    Full Member
    Minuteman
    Nov 5, 2009
    851
    609
    TX
    Does anyone have a good gunsmith who will do prefits for an Inpact 737r in 6mm ARC? My lathes are down for a move, and I’m out of touch with the current smiths out there. I’m trying to put together a lighter weight rifle for steel out to 1000y max, and was planning on a 6BR, but since I’ve already got all of the components 6 ARC seems like it’d do fine as well. Based on my 18” 6 ARC AR15 velocities with lower pressure loads (no issue at 1000), I was planning on doing the same with the bolt gun since it’ll run suppressed.


    newageroman

    Sergeant of the Hide
    Full Member
    Minuteman
    Jul 13, 2018
    163
    48
    www.brassbucket.net
    Is anyone else using the AMP Annealer on their brass?
    I just went through another 300 cases Sunday using Pilot#001 code:B and got a result of 140.
    This is for Starline once fired and 2x fired.
    Is the Annealing code stable throughout the life of the brass? Can I use 140 forever or do I need to sacrifice 1 to anayze every so often. Just some ponderings...

    I took a new friend to the range so we stayed under 500. I finished off some old plinking rounds with W748. He hadn't shot much past 100 so he had fun. We got his 308 on at 1/2/300yds. then I let him shoot the arc at 500. We were peppering a silhouette on the left side. There was a tad of wind so se had to hold left edge of target to hit center. Love shooting this AR. Only problem now is I can see my self turning into a glass snob. The Valdada is nice, I have a plan for my LR bolt rifle glass upgrade.

    I found 1k BR4 primers and 1k SPP and another bottle of Leverevolution on Friday. PrecisionReloading has LL in 8# jugs right now BTW...

    Anyone else get any fun stuff in recently?


    Gtscotty

    Gunny Sergeant
    Full Member
    Minuteman
    Jul 22, 2018
    584
    454
    Oooohhh. If I were looking for a barrel this one would be really high on my list...

    The only thing is that +2 gas system. I have a regular rifle length and I don't see any need to "+" anything...

    Oh man, I'm really going to need one of their ultra-match 18" fluted barrels. I've been looking for something exactly like that to replace or augment my heavy 21" Odin Works pig. After playing with the pig for a while, I really think a lighter 18" would be the perfect general ARC for my uses.

    Unfortunately I just started putting together an Origin or that 18" would be on it's way to my house. I was actually originally going to get a PPC bolt head with my origin and make it into a 6mm ARC, but no one keeps any ARC barrels in stock and It seems like most barrel shops are 18-20 weeks out on an order made today. Think I'll go GT instead this time, maybe next barrel will be an ARC once things slow down a bit.


    Gtscotty

    Gunny Sergeant
    Full Member
    Minuteman
    Jul 22, 2018
    584
    454
    Yep, I'd guess H4350 would be too slow and too bulky to be able to load enough to hit pressure. That's why LVR works so well, it's between the Varget and 4350 burn rates and is pretty dense. I have a lot of StaBall I'd like to try, and while it's slower even than H4350, it's pretty dense so you should be able to fit a decent load in that tiny case. Per the data, not enough to equal LVR, but I am curious how close it will get.

    • Like
    Reactions: A&8's

    ormandj

    Supporter
    Supporter
    Full Member
    Minuteman
    Nov 5, 2009
    851
    609
    TX
    Is anyone else using the AMP Annealer on their brass?
    I just went through another 300 cases Sunday using Pilot#001 code:B and got a result of 140.
    This is for Starline once fired and 2x fired.
    Is the Annealing code stable throughout the life of the brass? Can I use 140 forever or do I need to sacrifice 1 to anayze every so often. Just some ponderings...

    I took a new friend to the range so we stayed under 500. I finished off some old plinking rounds with W748. He hadn't shot much past 100 so he had fun. We got his 308 on at 1/2/300yds. then I let him shoot the arc at 500. We were peppering a silhouette on the left side. There was a tad of wind so se had to hold left edge of target to hit center. Love shooting this AR. Only problem now is I can see my self turning into a glass snob. The Valdada is nice, I have a plan for my LR bolt rifle glass upgrade.

    I found 1k BR4 primers and 1k SPP and another bottle of Leverevolution on Friday. PrecisionReloading has LL in 8# jugs right now BTW...

    Anyone else get any fun stuff in recently?
    You just run the analysis once unless you're changing the brand/neck wall thickness/lot of brass. If it's super consistent, lot doesn't really matter that much; some brands have a significant amount of lot-to-lot variance in which case that comes into play. I assume you're not neck turning because you're not an oddball like me, in which case you can generally collect brass and do analysis once, then use that code for the life of that batch of brass.


    A&8's

    Major Hide Member
    Full Member
    Minuteman
  • Can't get enough in the case to make much use of H4350.

    Yep, I'd guess H4350 would be too slow and too bulky to be able to load enough to hit pressure. That's why LVR works so well, it's between the Varget and 4350 burn rates and is pretty dense. I have a lot of StaBall I'd like to try, and while it's slower even than H4350, it's pretty dense so you should be able to fit a decent load in that tiny case. Per the data, not enough to equal LVR, but I am curious how close it will get.


    I kinda figured as much.

    I have some 2460 and power pro 4000mr I think I'll try. The PP4K may borderline too slow, too.


    It sucks that compared to when I started reloading (1991), I would look in the book, find the bullet, find 1/2 dozen powders. Go to the LGS and pick up a lb of each and try. Nowadays, you go to the LGS to see what powder is available and reverse engineer it.


    Clayman

    Sergeant of the Hide
    Full Member
    Minuteman
    Jul 29, 2021
    369
    410
    AZ
    Oooohhh. If I were looking for a barrel this one would be really high on my list...

    The only thing is that +2 gas system. I have a regular rifle length and I don't see any need to "+" anything...


    +2 equals shorter dwell length, delays unlocking, less chamber pressure, less gas in the face, much better suppressed.

    • Like
    Reactions: alamo5000

    r.tenorio671

    Private
    Full Member
    Minuteman
    Feb 19, 2017
    384
    264
    13° 28' 0" N / 144° 46' 59" E
    ...after searching for anyone using AR-Comp the threads seemed to die out once folks got hold of Lever and dropped the AR-Comp testing they were doing *sad* As I only have AR-Comp & 8208XBR available, wondering if folks that have tried either powder can post their results or message me their data. I understand that those powders will be better suited with <100gn projectiles so any info would be appreciated. I have some Nosler 105 RDF's and 70 grn Varmageddon's that I plan to start with once my 6.5Grendel Starline brass arrives. I'll be using a BA 18" barrel (only thing available @Brownells back in 2020).


    Gtscotty

    Gunny Sergeant
    Full Member
    Minuteman
    Jul 22, 2018
    584
    454
    +2 equals shorter dwell length, delays unlocking, less chamber pressure, less gas in the face, much better suppressed.
    My 21" with +2 gas runs very nicely with a can and the gas turned down, which is how I run it all the time. I did notice with 85gr bullets I had to turn the gas up a click or two even though I was using heavier charges, but I guess that makes sense.


    Gtscotty

    Gunny Sergeant
    Full Member
    Minuteman
    Jul 22, 2018
    584
    454
    +2 equals shorter dwell length, delays unlocking, less chamber pressure, less gas in the face, much better suppressed.
    My 21" with +2 gas runs very nicely with a can and the gas turned down, which is how I run it all the time. I did notice with 85gr bullets I had to turn the gas up a click or two even though I was using heavier charges, but I guess that makes sense.


    Ledzep

    Chancellor
    Full Member
    Minuteman
  • Jun 9, 2009
    3,579
    3,328
    NE
    Fed 205's and CCI 450's here. No problems with consistency to report with the 450's.
